Waveshare LED-Display 1.54 200×200 ePaper Display Modul mit SPI Interface

Übersicht This is an E-Ink display module, 1.54inch, 200x200 resolution, with embedded controller, communicating via SPI interface, supports partial refresh. Due to the advantages like ultra low power consumption, wide viewing angle, great effect under sunlight, it is an ideal choice for applications such as shelf label, industrial instrument, and so on. Eigenschaften No backlight, keeps displaying last content for a long time even when power down Ultra low power consumption, basically power is only required for refreshing SPI interface, for connecting with controller boards like Raspberry Pi/Arduino/Nucleo, etc. Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32) Spezifikationen Operating voltage: 3.3V Interface: 3-wire SPI, 4-wire SPI Outline dimension: 48mm × 33mm Display size: 27.6mm × 27.6mm Dot pitch: 0.138 × 0.138 Resolution: 200 × 200 Display color: black, white Grey level: 2 Partial refresh time: 0.3s Full refresh time: 2s Refresh power: 26.4mW(typ.) Standby power: <,0.017mW Viewing angle: >,170° Interface SYMBOL DESCRIPTION VCC 3.3V GND Ground DIN SPI MOSI pin CLK SPI SCK pin CS SPI chip selection, low active DC Data/Command selection (high for data, low for command) RST External reset, low active BUSY Busy status output, low active Lieferumfang 1.54inch e-Paper Module Cable XH2.54 20cm 8Pin Dokumentation / Downloads http://www.waveshare.com/wiki/1.54inch_e-Paper_Module
